TOUCH TIMER ACTIVATOR
TOUCH TIMER PLUS

Please refer to our website Instrukcje są również dostępne w innych językach. These instructions are available in other languages. In the unlikely event that you have to return your product, please ensure you switch the battery off fi rst. Please call the Technical helpline before returning any products to your stockist. Failure to adhere to the instructions will invalidate the warranty.įor further help or assistance or information on this or other products in the range please call the Elkay Technical team on +44 (0)28 9061 6505.

TOUCH TIMER ACTIVATOR

The Activator PIR unit will only trigger the lights or application if the ambient light level is below what has been set on the lux level adjustment.Īll wiring should be carried out by a competent person or a qualified electrician and should be fitted to current IEE wiring regulations BS 7671.The circuit should be isolated before carrying out any work. If no one is present in the room or the detection zone is not passed through during its set time period, the timer will time out turning off the lights or appliance and the blue indicator ring will light up.

The unit will then wait 10 to 15 seconds approximately before allowing the PIR unit to sense and re-trigger the timing period again. Each time the Activator PIR is triggered the red LED will fl ash once and reset the timer on the master unit it is connected to, back to the start of the timing period. PIR Activator only– In standard operation the PIR Activator will now sense body heat when passing through the detection zone. The blue locator ring will then illuminate once the light or appliance is switched OFF. To prematurely end the timing of the Push/Touch master timer, press and hold the pushbutton/touch for 2.5 seconds and the pre-set delay time will time out after 60 seconds and switch OFF, during this time-out period the red LED on the master will fl ash continuously. When the timing period is 30 minutes, if the pushbutton/touchpad is pressed 15 minutes into sequence, the timer will restart for a further 30 minutes. PIR Activator only– Leave the area and wait for the Master Timer to switch OFF providing no further movement are detected, re-enter the area and the PIR will detect movement and trigger the unit initiating the timing sequence on the Master unit it is attached to and switch the light source or appliance ON.Īll timers– At any time during the working of the light source, load or appliance, the pushbutton/ touchpad can be pressed to reset the timing sequence on the master unit to the originally set time, e.g. Following installation set-up, test each Activator for functionally with the Master timer delay timing set to the minimum setting.Turn mains power ON and follow the appropriate Master Timer Installation steps/ instruction. Securely connect the Live In, Live Out and Trigger cables into terminals marked Lin, Lout & T between the Master and Activator units.

Upon completion, re-adjust the lux level pot to the desired level of operation.

TOUCH TIMER PLUS

PIR Activator only Initially during the setting up process, adjust the lux-pot at the back of the unit anti-clockwise toward the plus (+).

PIR and Touch Activators only Ensure the battery jumper tag Battery located at the back of the unit on the right-hand corner is fitted across the outer 2 pins as below.

Please select the appropriate wiring diagram as per Master and Activator combinations (see diagram 1 & 2). Please note the Touch and PIR activator must have a three-core connection to the Master but the Push Button can sacrifice the blue locator ring at the activators if a third core is not available. Results have a live in, live out and trigger cable cores running between the Master and Activator identified.

Turn off mains supply before installation.

See appropriate wiring diagram (see diagram 1 & 2).
